PTFIX series single-inputmulti-output splitterHAITIAN
Categories
Tags
Place of Origin
Zhejiang,China
Model Number
1 in, 10 out, 1 in, 11 out, 1 in, 12 out, 1 in, 13 out, 1 in, 14 out, 1 in, 15 out, in, 16 out, 1 in, 17 out, 1 in, 18 out, 1 in, 19 out, 1 in, 20 out, 1 in, 22 out, 1in, 23 out, 1 in, 24 out, 1 in, 3 out, 1 in, 4 out, 1 in, 5 out, 1 in, 6 out, 1 in, 7out. 1 in.8 out. 1 in.9 out
Connection Method
Push-In Connection
Color
grey, Red, yellow
Rated Current
24A
Rated Voltage
690V
Mounting
Din rail
Material of Shell
Nylon PA66
Metal Material
Copper
Why Choose Shengling PTFIX DistributionBlocks?
Shengling focuses on electrical connection products, delivering efficient andreliable solutions through stable quality and mature manufacturingprocesses.
For PTFIX distribution blocks, Shengling optimizes the design for practicalinstallation needs, making wiring faster, safer, and more organized. Thepush-in connection allows tool-free wiring, greatly improving installationefficiency-ideal for control cabinets and compact distribution boxes.
Key advantages:
- Fast wiring: Push-in design, no screws required
- One-in, multiple-out: Simplifies wiring and keeps layouts neat
- Flexible mounting: DIN rail compatible with secure fixing options
- Safe and reliable: Quality conductive parts with durable insulation
Screw-fixing clips
The clips snap into the slots on both sides of the terminal for screw-fixing.
Screw-fixing clips
The clips snap into the slots on both sides of the terminal for screw-fixing.
Screw-fixing clips
The clips snap into the slots on both sides of the terminal for screw-fixing.
What materials are used internally in the PTFIX series one-input multiple-output splitter?
High conductivity, copper.
conductive plate. Made with a thickened copper conductive plate, itis oxidation-resistant and has excellent conductivity. Stainless steelspring clips ensure a tight, secure connection.
How to install the PTFIX series one-input multiple-output splitter on the guide rail?
PTFIX one-input multiple-output splitters are available in bothhorizontal and vertical mounting configurations.
The guide rail clips are secure and will not loosen. The installationmethod can be selected according to the environment, and screwscan also be used for fixing.
What other advantages do the PTFIX series single-input multi-output splitters have?
The wires are clamped tightly and will not come loose.
Strip 10mm2 of wire and insert it all the way in, ensuring noexposed wires to prevent arcing; it can withstand a 10KG pullingforce.
How to wire a PTFIX one-input, multiple-output splitter?
The PTFIX series single-input multi-output splitter is a direct-plugpush-button design.
Safe, simple, easy to connect circuits, and improves spaceutilization.
Installation is very simple:
1. Press the clips with a screwdriver.
2. Insert the wires into the connection holes one by one.
PTFIX One-input Multiple-output Splitte rWiring Video
Want to see more terminal wiring videos?
Then follow me!
